ZyXEL 8xGb switch, plast, green GS-108Sv2 GS-108SV2-EU0101F
ZyXEL 8xGb switch, plast, green GS-108Sv2 GS-108SV2-EU0101F
Popis produktu:
ZyXEL GS-108S v2 je stolový switch Gigabit Ethernet s 8 portami, ktorý jednoducho pripojí mnoho zariadení na domácej sieti. Nová konštrukcia zariadenia navyše optimalizuje streamovanie videa a online hranie.
System Specifications
Standard
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3 Nway auto-negotiation
IEEE 802.3x full duplex operation and flow control
IEEE 802.3az Energy Efficient Ethernet
Performance
Data transfer rate (half duplex/full duplex):
Ethernet: 10/20 Mbps
Fast Ethernet: 100/200 Mbps
Gigabit Ethernet: 1000/2000 Mbps
MAC address table: 8 K
Memory buffer: 128 KB
Switching fabric (non-blocking): 16 Gbps
Features
Auto-MDI/MDIX in all ports
Transmission method:
Store-and-forward architecture
Port-based Quality of Service (QoS) support
Jumbo Frame support up to 9 KB
Hardware Specifications
Interface
Eight RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support
QoS Ports
Two high-priority QoS ports, two medium-priority QoS ports, and four lowpriority QoS ports
LED Indicator
PWR: Power
Per port: Link/Activity
Amber: 10/100 Mbps
Green: 1000 Mbps
Power supply
Input: 100 to 240 V AC
Output: 5 V DC, 1 A
Power Consumption: 3.0 watt max.
Physical Specifications
Item dimensions (WxDxH): 152 x 80 x 32 mm (5.99” x 3.15” x 1.26”)
Item weight: 150 g (0.33 lb.)
Packing dimensions (WxDxH): 157 x 86 x 96 mm (6.18” x 3.39” x 3.78”)
Packing weight: 250 g (0.55 lb.)
Environmental Specifications
Operating Environment
Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10% to 90% (Non-condensing)
Storage Environment
Temperature: -20°C to 70°C (-40°F to 158°F)
Humidity: 10% to 90% (Non-condensing)
Certification
CE, FCC Class B, BSMI
Packing Contents
Gigabit switch
Power adapter
User’s guide
Warranty card
Stránky o produkte:
https://www.zyxel.com/sk/sk/products_services/gs_108s_v2.shtml?t=p
Technické špecifikácie sa môžu meniť bez predošlého upozornenia. Obsah aktuálneho balenia sa môže líšiť v závislosti od dátumu predaja. Obrázky majú len informatívny charakter.
ZyXEL GS-108S v2 je stolový switch Gigabit Ethernet s 8 portami, ktorý jednoducho pripojí mnoho zariadení na domácej sieti. Nová konštrukcia zariadenia navyše optimalizuje streamovanie videa a online hranie.
System Specifications
Standard
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3 Nway auto-negotiation
IEEE 802.3x full duplex operation and flow control
IEEE 802.3az Energy Efficient Ethernet
Performance
Data transfer rate (half duplex/full duplex):
Ethernet: 10/20 Mbps
Fast Ethernet: 100/200 Mbps
Gigabit Ethernet: 1000/2000 Mbps
MAC address table: 8 K
Memory buffer: 128 KB
Switching fabric (non-blocking): 16 Gbps
Features
Auto-MDI/MDIX in all ports
Transmission method:
Store-and-forward architecture
Port-based Quality of Service (QoS) support
Jumbo Frame support up to 9 KB
Hardware Specifications
Interface
Eight RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support
QoS Ports
Two high-priority QoS ports, two medium-priority QoS ports, and four lowpriority QoS ports
LED Indicator
PWR: Power
Per port: Link/Activity
Amber: 10/100 Mbps
Green: 1000 Mbps
Power supply
Input: 100 to 240 V AC
Output: 5 V DC, 1 A
Power Consumption: 3.0 watt max.
Physical Specifications
Item dimensions (WxDxH): 152 x 80 x 32 mm (5.99” x 3.15” x 1.26”)
Item weight: 150 g (0.33 lb.)
Packing dimensions (WxDxH): 157 x 86 x 96 mm (6.18” x 3.39” x 3.78”)
Packing weight: 250 g (0.55 lb.)
Environmental Specifications
Operating Environment
Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10% to 90% (Non-condensing)
Storage Environment
Temperature: -20°C to 70°C (-40°F to 158°F)
Humidity: 10% to 90% (Non-condensing)
Certification
CE, FCC Class B, BSMI
Packing Contents
Gigabit switch
Power adapter
User’s guide
Warranty card
Stránky o produkte:
https://www.zyxel.com/sk/sk/products_services/gs_108s_v2.shtml?t=p
Technické špecifikácie sa môžu meniť bez predošlého upozornenia. Obsah aktuálneho balenia sa môže líšiť v závislosti od dátumu predaja. Obrázky majú len informatívny charakter.
Dodatočné parametre
| Kategória: | Prepínače (switch) |
|---|---|
| Záruka: | 24 mesiacov |
| Hmotnosť: | 0.26 kg |
