Technical Specifications
Mechanical
Dimensions O48 x 107.5 mm (O1.9 x 4.2")
Weight 170 g (6 oz)
Enclosure material Polycarbonate
Mount material Polycarbonate
Weatherproofing IPX4
Resistance IK04
Optics
Sensor 5MP CMOS sensor
Lens Fixed focal length
View angle H: 102.4°, V: 54.9°, D: 120.6°
Night mode Built-in IR LED illumination and IR cut filter
Video
Video compression H.264
Resolution 2688 x 1512 (16:9)
Max. frame rate 30 FPS
Image settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
System
Processor Dual-core Arm® Cortex®-A7 based chip
Networking interface 10/100 MbE RJ45 port
Max. power consumption 4W
Power method PoE
Supported voltage range 37—57V DC
LED R/G/B/W
Button Factory reset
Mounting Desktop, wall, pole, hard-ceiling (Included)
Ceiling, conduit (Sold separately)
Operating temperature -20 to 40o C (-4 to 104o F)
Operating humidity 0 to 90% noncondensing
Certifications FCC, IC, CE
Audio
Microphone Yes (Can be disabled)
Software
Web application UniFi Protect: Version 2.2.7 or 2.7.28 and later
Mobile app UniFi Protect iOS™ and Android™: Version 1.10.0 and later
Mechanical
Dimensions O48 x 107.5 mm (O1.9 x 4.2")
Weight 170 g (6 oz)
Enclosure material Polycarbonate
Mount material Polycarbonate
Weatherproofing IPX4
Resistance IK04
Optics
Sensor 5MP CMOS sensor
Lens Fixed focal length
View angle H: 102.4°, V: 54.9°, D: 120.6°
Night mode Built-in IR LED illumination and IR cut filter
Video
Video compression H.264
Resolution 2688 x 1512 (16:9)
Max. frame rate 30 FPS
Image settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
System
Processor Dual-core Arm® Cortex®-A7 based chip
Networking interface 10/100 MbE RJ45 port
Max. power consumption 4W
Power method PoE
Supported voltage range 37—57V DC
LED R/G/B/W
Button Factory reset
Mounting Desktop, wall, pole, hard-ceiling (Included)
Ceiling, conduit (Sold separately)
Operating temperature -20 to 40o C (-4 to 104o F)
Operating humidity 0 to 90% noncondensing
Certifications FCC, IC, CE
Audio
Microphone Yes (Can be disabled)
Software
Web application UniFi Protect: Version 2.2.7 or 2.7.28 and later
Mobile app UniFi Protect iOS™ and Android™: Version 1.10.0 and later
Dodatočné parametre
| Kategória: | IP kamery s WiFi |
|---|---|
| Záruka: | 24 mesiacov |
| Hmotnosť: | 0.34 kg |
