Transcend 512MB PATA (IDE) PTM820 FLASH Module (44 Pin HORIZONTAL), SLC TS512MPTM820
Transcend 512MB PATA (IDE) PTM820 FLASH Module (44 Pin HORIZONTAL), SLC TS512MPTM820
Transcend 512MB PATA (IDE) PTM820 FLASH Module (44 Pin HORIZONTAL), SLC
Transcend's 44-pin PATA PTM820 Flash Module can be inserted directly to the PATA (IDE) interface of a motherboard to replace conventional 2.5" hard disk drives. Ideal for use as bootable drives, the 44-pin PATA PTM820 Flash Module is an easy solution for integrating SSD storage technology into laptop-based legacy systems.
Features:
RoHS compliant
Support Security command
Support S.M.A.R.T (Self-defined)
Fully compatible with devices and OS that support the IDE standard (pitch = 2.00mm)
Built-in ECC function assures high reliability of data transfer
Supports up to Ultra DMA Mode 4
Supports PIO Mode 6
SLC NAND Flash
Specifications:
Interface (connector): IDE 44P
Form Factor: IDE Flash Module
Flash Type: SLC
Capacity(MB): 512MB
Max. Performance (Vary by density)
- Read: 21MB/s
- Write: 23MB/s
Op. Voltage(V): 3.3V±5% or 5V±10%
Power Consumption (W): 0.45W
Op. Temp.(?): 0?~70?
Storage Temp.(?): -40?~85?
Humidity(%): 0%~95%
Shock(G): 1500G, 0.5ms, 3 axis
Vibration(Hz/G). 20G (Peak-to-Peak), 20Hz to 2000Hz(Frequency)
Dimensions(mm): 46.0mm × 28.0mm × 6.0mm (without housing)
MTBF(hours): 1,000,000 hours
Transcend's 44-pin PATA PTM820 Flash Module can be inserted directly to the PATA (IDE) interface of a motherboard to replace conventional 2.5" hard disk drives. Ideal for use as bootable drives, the 44-pin PATA PTM820 Flash Module is an easy solution for integrating SSD storage technology into laptop-based legacy systems.
Features:
RoHS compliant
Support Security command
Support S.M.A.R.T (Self-defined)
Fully compatible with devices and OS that support the IDE standard (pitch = 2.00mm)
Built-in ECC function assures high reliability of data transfer
Supports up to Ultra DMA Mode 4
Supports PIO Mode 6
SLC NAND Flash
Specifications:
Interface (connector): IDE 44P
Form Factor: IDE Flash Module
Flash Type: SLC
Capacity(MB): 512MB
Max. Performance (Vary by density)
- Read: 21MB/s
- Write: 23MB/s
Op. Voltage(V): 3.3V±5% or 5V±10%
Power Consumption (W): 0.45W
Op. Temp.(?): 0?~70?
Storage Temp.(?): -40?~85?
Humidity(%): 0%~95%
Shock(G): 1500G, 0.5ms, 3 axis
Vibration(Hz/G). 20G (Peak-to-Peak), 20Hz to 2000Hz(Frequency)
Dimensions(mm): 46.0mm × 28.0mm × 6.0mm (without housing)
MTBF(hours): 1,000,000 hours
Dodatočné parametre
| Kategória: | SSD mSATA, M.2, PCIe |
|---|---|
| Záruka: | 24 mesiacov |
| Hmotnosť: | 0.01 kg |
| Kapacita pamäťovej karty: | menej ako 1 GB |
| GPSR: | Transcend Information, Inc;Cairostraat 40,3047,Rotterdam,Nederland;service-tw@transcend-info.com |
| Rozhranie (pevné disky): | ATA |
| Rozhranie (flash moduly): | IDE |
| Výrobca (pevné disky): | Transcend |
