TP-LINK "AX3000 Dual-Band Wi-Fi 6 RouterSPEED: 574 Mbps at 2.4 GHz + 2402 Mbps at 5 GHzSPEC: 4× Antennas, MediaTek Dua EX520 TP-link

Popis produktu

EX520

AX3000 Dual Band Wi-Fi 6 Router

Dual-Band Wi-Fi 6: Rýchlosť až 3000 Mbps - 2402 Mbps na 5 GHz a 574 Mbps na 2,4 GHz.*

Rozšírené pokrytie: Štyri vysoko výkonné antény a technológie Beamforming zaisťujú silné a spoľahlivé WiFi pokrytie po celom dome.

Viac pripojení: Technológie OFDMA a MU-MIMO zvyšujú kapacitu a umožňujú súčasný prenos dát na viac zariadení.**

EasyMesh: Vytvorte chytrú mesh sieť s plynulým pokrytím a väčšou flexibilitou vďaka štandardnej mesh technológii.

Vylepšené zabezpečenie: Šifrovanie WPA3, Multi-SSID a rodičovská kontrola poskytujú personalizované a bezpečnejšie online prostredie.

Gigabitové káblové pripojenia: 1x gigabitový WAN port a 4x gigabitové LAN porty zaisťujú rýchly a flexibilný prístup k internetu.

Jednoduché nastavenie: Nastavte svoju sieť v priebehu niekoľkých minút pomocou výkonnej aplikácie Aginet.

Vzdialená správa: Podpora TAUC (TP-Link Aginet Unified Cloud) a protokolov TR-069, TR-098, TR-181, TR-111 a TR-143.



HARDWARE FEATURES

Interface 1× 10/100/1000 Mbps RJ45 WAN Port

4× 10/100/1000 Mbps RJ45 LAN Ports

Button Power On/Off Button, Reset Button, Wi-Fi/WPS Button

External Power Supply 12V/1.5A

Dimensions ( W x D x H ) 10.2 × 5.3 × 1.5 in (260.2 × 135.0 × 41.6 mm)

Antenna Type Four high-performance external antennas

WIRELESS FEATURES

Wireless Standards IEEE 802.11a/n/ac/ax 5 GHz

IEEE 802.11b/g/n/ax 2.4 GHz

Frequency 2.4 GHz and 5 GHz

Signal Rate AX3000

5 GHz: Up to 2402 Mbps

2.4 GHz: Up to 574 Mbps

Wireless Functions Enable/Disable Wireless Radio, WMM, Wireless Statistics

Wireless Security WPA/WPA2/WPA3 encryptions

Transmission Power CE:<20dBm (2.4GHz); <23dBm (5.15GHz–5.35GHz); <30dBm (5.47GHz–5.725GHz)

Multi-SSID 2× 5 GHz Multi-SSID

2× 2.4 GHz Multi-SSID

Wireless Schedule Support 2.4 GHz and 5 GHz Wireless Schedule

Mesh Technology EasyMesh compatible, and support 802.11k/v/r

SOFTWARE FEATURES

Quality of Service Hardware QoS, Flow Classification

Advanced Features TX Beamforming, MU-MIMO, DL/UL OFDMA, Airtime Fairness

Operating Modes Router, Access Point

WAN Type Dynamic IP/Static IP/PPPoE/PPTP/L2TP(Multi-EWAN)

Management Local management: WebGUI, Aginet app (for end users)

Remote management :Aginet ACS, TR-069, TR-098, TR-181, TR-369, TR-111,TR-143 for service providers

Aginet APP for end user (need to log in wtih TP-Link ID and bind your device to it)

Cloud management: TP-Link Aginet Unified Cloud (TAUC)

DHCP Server, DHCP Client List, Address Reservation

Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ

Dynamic DNS DynDns, NO-IP

VPN Pass-Through IPSec, PPTP, L2TP

Access Control Parental Controls, White List, Black List

Firewall Security DoS, SPI Firewall, IP and MAC Address Binding

Protocols IPv4, IPv6

VPN Server PPTP, OpenVPN, IPSec

OTHERS

Certification CE

Package Contents WiFi 6 Router EX520

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

Requirements Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux

Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser

Subscription with an internet service provider (for internet access)

Environment Operating Temperature: 0?–40? (32?–104?)

Storage Temperature: -40?–60? (-40?–140?)

Operating Humidity: 10%–90% non-condensing

Storage Humidity: 5%–90% non-condensing
