SG6428X 24G stack L3 4x10G SFP+ switch TP-link

SG6428X

Omada 24portový gigabitový stohovateľný spravovaný switch L3 so 4 slotmi 10G

24× gigabitových portov RJ45 a 4× 10 Gb/s slotov SFP+

Prepínacia kapacita 128 Gb/s na jednotku

Fyzické stohovanie pre integrovanú redundanciu a výkonnosť

Funkcia L3: RIP, OSPF, ECMP, VRRP, PIM-DM, DHCP Server/Relay

Stratégia zabezpečenia: ACL, zabezpečenie portov, DoS Defend, 802.1X

Vysoká dostupnosť vďaka dvom interným pevným zdrojom napájania, VRRP a ERPS

Centralizovaná správa cloudu prostredníctvom radiča Omada SDN

Samostatná správa cez web, CLI, SNMP a RMON



HARDWARE FEATURES

Interface • 24× 10/100/1000 Mbps RJ45 Ports

• 4× 10G SFP+ Slots

• 2× USB 2.0 Ports

• 1× RJ45 Console Port

• 1× USB Type-C Console Port

• 1× RJ45 Management Port

Fan Quantity Four Internal Fixed Fans

Power Supply Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz)

Dimensions ( W x D x H ) 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm)

Mounting Rackmountable

Max Power Consumption 28.4 W (220 V/50 Hz)

Max Heat Dissipation 96.91 BTU/hr (220 V/50 Hz)

PERFORMANCE

Switching Capacity 128 Gbps per Unit

Stacking • Stacking Number: 8

• Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports)

• Stack Bandwidth: Up to 80 Gbps (4 stack ports)

Packet Forwarding Rate 95.2 Mpps

MAC Address Table 32 K

Packet Buffer Memory 3 MB

Jumbo Frame 9 KB

SOFTWARE FEATURES

Quality of Service • Class of Service

- 8 Queues of Priority

- Port Priority

- IEEE 802.1p Priority

- DSCP Priority

- Queue Min-Bandwidth

- Schedule Mode (SP, WRR, SP+WRR)

• Bandwidth Control

- Rate Limit

- Storm Control

• Voice VLAN

• User-Defined OUI

• Smoother Performance

• Action for Flows

- QoS remark (802.1P Remark, DSCP Remark)

L3 Features • IP Interfaces:

- IPv4: Max 256, IPv6: Max 256

• Static Routing

- Max 1,024, IPv6: Max 512

• Host Route Table: Max 6,100 entries

• RIP: Version v1/v2, Max 8,190

• OSPF: Version v2/v3; v2: Max 8,190, v3: Max 4,097

• VRRP: Version v2/v3, Max 64 groups

• ECMP: 256 entries, max 32 ECMP Nexthops per Destination

• Static ARP: 512 static entries

• Dynamic ARP: 7,680 dynamic entries

• Proxy ARP

• DHCP Server:

- Max 8K IP Pools

- Max 1,000 Manual Binding Entries

• DHCP Relay:

- Relayed Interface

- Relayed VLAN

L2 and L2+ Features • Link Aggregation

• Spanning Tree Protocol

• Port-based and VLAN-based Loopback Detection

• 802.3x Flow Control

• Supports 2,048 IGMP groups

• ERPS

• Mirroring

• RSPAN

• MAC Address Table

• PIM-DM (IPv4)

• Multicast

- IGMP Snooping

- MLD Snooping

- L2 Multicast Table

- Fast Leave

- Multicast VLAN Registration (MVR)

- Static Multicast IP

- Multicast Filtering

Advanced Features • Automatic Device Discovery†

• Batch Configuration†

• Batch Firmware Upgrading†

• Intelligent Network Monitoring†

• Abnormal Event Warnings†

• Unified Configuration†

• Reboot Schedule†



ISP Features:

• 802.3ah Ethernet Link OAM

• L2PT (Layer 2 Protocol Tunneling)

• Device Link Detect Protocol (DLDP)

• DDM

• sFlow

VLAN • Max 4K VLAN Group (802.1q VLAN)

• 802.1Q Tagged VLAN

• MAC VLAN Entries: 200

• Multicast VLAN

• Management VLAN

• VLAN VPN (QinQ): Max 256 entries

• GVRP

• Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries

• VLAN VPN

• Voice VLAN

• Private VLAN

Security • Port Isolation

• CPU-Defend

• ARP Inspection (Dynamic ARP Inspection)

• DoS Defend

• IP-MAC-Port Binding

-1,024 Entries

- DHCP Snooping

- ARP Inspection

- IPv4 Source Guard

• IPv6-MAC

-Port Binding

-1,024 Entries

- DHCPv6 Snooping

- ND Detection

- ND Snooping

- IPv6 Source Guard

• DHCP Filter

• Static/Dynamic Port Security

- Up to 64 MAC addresses per port

• Broadcast/Multicast/Unknown-unicast Storm Control

- kbps/ratio control mode

• 802.1X

- Port base authentication

- Mac base authentication

- VLAN Assignment

- MAB

- Guest VLAN

- RADIUS authentication and accountability support

• AAA (including TACACS+)

• Secure web management through HTTPS with SSLv3/TLS 1.2

• Secure Command Line Interface (CLI) management with SSHv2

• IP/Port/MAC-based access control

MANAGEMENT

Omada App Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Centralized Management • Omada Cloud-Based Controller

• Omada Hardware Controller

• Omada Software Controller

Cloud Access Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Zero-Touch Provisioning Yes. Requiring the use of the Omada Cloud-Based Controller.

Management Features • Web-based GUI

• Command Line Interface (CLI) through console port, telnet

• SNMPv1/v2c/v3

- Trap/Inform

- RMON (1, 2, 3, 9 groups)

• SDM Template

• DHCP/BOOTP Client

• 802.1ab LLDP/LLDP-MED

• DHCP Auto Install

• Dual Image, Dual Configuration

• CPU Monitoring

• Cable Diagnostics

• Password Recovery

• SNTP

• System Log

• EEE

OTHERS

Package Contents • SG6428X Switch

• 2× Power Cords

• RJ45 Console Cable

• Quick Installation Guide

• Rackmount Kit

• Rubber Feet

System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.

Environment • Operating Temperature:

-5 °C to 50 °C (23 °F to 122 °F) @ 300 meters

-5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters

-5 °C to 40 °C (23 °F to 104 °F) @ 3,000 meters



• Storage Temperature: -40 °C to 70 ? (-40 ? to 158 ?)

• Operating Humidity: 10–90% RH non-condensing

• Storage Humidity: 5–90% RH non-condensing
