Specifications
Details |
|---|
Product code |
RBmAP2nD |
Architecture |
MIPSBE |
CPU |
QCA9531 |
CPU core count |
1 |
CPU nominal frequency |
650 MHz |
Dimensions |
68x68x19mm |
License level |
4 |
Operating System |
RouterOS |
Size of RAM |
64 MB |
Storage size |
16 MB |
Storage type |
FLASH |
Tested ambient temperature |
-20°C to 70°C |
Powering
Details |
|---|
MicroUSB input Voltage |
5-5 V |
PoE in |
802.3af/at |
PoE out |
Passive PoE |
PoE in input Voltage |
12-57 V |
Number of DC inputs |
3 (DC jack, MicroUSB, PoE-IN) |
DC jack input Voltage |
8-57 V |
Max out per port output (input < 30 V) |
0.5 A |
Max total out (A) |
0.5 A |
Max power consumption |
5 W |
Wireless
Details |
|---|
Wireless 2.4 GHz number of chains |
2 |
Wireless 2.4 GHz Max data rate |
300 Mbit/s |
Wireless 2.4 GHz standards |
802.11b/g/n |
Antenna gain dBi for 2.4 GHz |
1.2 |
Wireless 2.4 GHz chip model |
QCA9531 |
Ethernet
Details |
|---|
10/100 Ethernet ports |
2 |
Peripherals
Details |
|---|
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
microUSB type AB |
Max USB current (A) |
1 |
Other
Details |
|---|
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Wireless specifications
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
|---|
1MBit/s |
22 |
-96 |
11MBit/s |
22 |
-89 |
6MBit/s |
20 |
-93 |
54MBit/s |
18 |
-74 |
MCS0 |
20 |
-93 |
MCS7 |
16 |
-71 |
