Specifications
Details |
|---|
Product code |
CRS305-1G-4S+OUT |
Architecture |
ARM 32bit |
CPU |
98DX226S |
CPU core count |
2 |
CPU nominal frequency |
800 MHz |
RouterOS license |
5 |
Operating System |
RouterOS v7 / SwOS |
Size of RAM |
256 MB |
Storage size |
16 MB |
Storage type |
FLASH |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
Number of DC inputs |
3 (DC jack, PoE-IN, 2-pin terminal) |
DC jack input Voltage |
24-57 V |
2-pin terminal input Voltage |
24-57 V |
Max power consumption |
17 W |
Max power consumption without attachments |
7 W |
Cooling type |
Passive |
PoE in |
802.3af/at |
PoE in input Voltage |
42-57 V |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
1 |
Fiber
Peripherals
Details |
|---|
Serial console port |
RJ45 |
Other
Details |
|---|
CPU temperature monitor |
Yes |
Certification & Approvals
Details |
|---|
Certification |
CE, EAC, ROHS |
IP |
IP66 |
