Honeywell Granit 1920 i-USB KIT: 1D/2D, PDF, DPM 1920IDPM-3USB

Popis produktu

Industrial Direct Part Mark (DPM) Area-Imaging Scanner MECHANICAL Dimensions (L x W x H): 134 mm x 74.5 mm x 193 mm (5.27 in x 2.93 in x 7.6 in) Weight: 312 g (11 oz) ELECTRICAL Input Voltage: 4.0V DC - 5.5V DC Operating Power: 2.35 W (470 mA @5V DC) Standby Power: 0.5 W (100 mA @5V DC) Host System Interfaces: USB, RS-232, Keyboard Wedge ENVIRONMENTAL Operating Temperature: -30°C to 50°C (-22°F to 122°F) Storage Temperature: -40°C to 70°C (-40°F to 158°F) Humidity: Up to 95% relative humidity, non-condensing Drop: Designed to withstand 50 2 m (6.5 ft) drops to concrete at -30°C (-22°F) Tumble: 5,000 1 m (3.3 ft) tumbles Environmental Sealing: IP65 Light Levels: 0 to 100,000 lux ESD: ±20 kV air discharge, ±8 kV contact discharge SCAN PERFORMANCE Scan Pattern: Area Imager Scan Angle: Horizontal: 41.4°, Vertical: 32.2° Symbol Contrast: 25% minimum reflectance difference Min. Resolution: 1D 2.5 mil, 2D 4 mil Pitch, Skew: 1D: ±45°, ±65°, 2D: ±45°, ±45° Reading Indicators: LED, Beeper and Vibrator Decode Capability: Reads standard 1D, stacked, 2D and postal symbologies Warranty: 3-year factory warranty
