ASUS TUF-RX7800XT-O16G-GAMING 16GB/256-bit GDDR6 HDMI 3xDP 90YV0JJ0-M0NA00 Asus

ASUS TUF Gaming Radeon™ RX 7800 XT OC Edition 16GB GDDR6 optimized inside and out for lower temps and durability.

Axial-tech fans scaled up to deliver 24% more airflow
Dual ball fan bearings last up to twice as long as conventional designs
Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable
Metal Exoskeleton adds structural rigidity and vents to increase heat dissipation
Auto-Extreme precision automated manufacturing for higher reliability
GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring

Model
TUF-RX7800XT-O16G-GAMING
Graphic Engine
AMD Radeon™ RX 7800 XT
Bus Standard
PCI Express 4.0
OpenGL
OpenGL®4.6
Video Memory
16GB GDDR6
Engine Clock
OC mode : up to 2565 MHz (Boost Clock)/up to 2254 MHz (Game Clock)
Default mode : up to 2520 MHz (Boost Clock)/up to 2213 MHz (Game Clock)
Stream Processors
3840
Memory Speed
19.5 Gbps
Memory Interface
256-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 1 (Native HDMI 2.1)
Yes x 3 (Native DisplayPort 2.1)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x TUF certificate of Reliability
1 x TUF Gaming Graphics Card Holder
1 x TUF Velcro Hook & Loop
1 x Collection card
1 x Thank you card
1 x Speedsetup Manual
Software
ASUS GPU Tweak III & Drivers: please download all software from the support site.
Dimensions
319.8 x 150.9 x 59.2 mm
12.6 x 5.94 x 2.33 inch
Recommended PSU
750W
Power Connectors
2 x 8-pin
Slot
2.96 Slot
AURA SYNC
ARGB
